The DVM app is a digital voltage meter or digital
current meter readout that floats on the top left-
hand side of the screen. However, please note that
if the cursors (refer to page 60) are turned on, the
DVM readout will be replaced by the cursor
readout.
The DVM app allows you to measure the AC RMS,
DC, DC RMS, Duty and frequency of an input
signal. This software is especially useful for those
measurement applications that require both a DSO
and a basic DVM to be used at the same time.
Basic Features:
CAT I 300Vrms input
3 digit resolution for voltage measurements
5 digit resolution for frequency
Input channel selection
