GW Instek GDS-2000E Series User Manual

GDS-2000E Series User Manual
200
Panel Operation
Choose the DVM application from the
APP menu. See page 193.
Set Source
1. Press Source and select the source
channel for the DVM. The probe
type setting (voltage or current)
determines whether the function
acts as a digital volt meter or as a
digital current meter for the
selected source. See page 119 to set
the probe type.
Source
CH1 ~ CH4
Mode
The Mode setting determines the measurement
mode for the meter.
2. Press Mode and select the mode.
Mode
AC RMS, DC, DC RMS, Duty,
Frequency
Turn On/Off
3. Press DVM and toggle DVM on.
The DVM app will remain running
in the background even if other
functions are turned on.
