GW Instek GDS-2000E Series User Manual

GDS-2000E Series User Manual
232
Recall Default Panel Setting
Panel Operation
1. Press the Default key.
Default
2. The screen will update with the default panel
settings.
Setting Contents
The following is the default (factory) setting
contents.
Acquire
Mode: Sample
XY: OFF
Record Length: 10k
Expand: By Center
Display
Mode: Vector
Persistence: 240ms
Waveform intensity: 50%
Graticule intensity: 50%
Backlight Intensity: 80%
Backlight Auto-dim: On
Time: 10min
Graticule: full
Channel
Scale: 100mV/Div
CH1: On
Coupling: DC
Impedance: 1MΩ
Invert: Off
Bandwidth: full
Expand: By Ground
Position: 0.00V
Probe: Voltage
Probe attenuation: 1x
Deskew: 0s
Cursor
Horizontal cursor: Off
Vertical Cursor: Off
Measure
Source: CH1
Gating: Screen
Display All: Off
High-Low: Auto
Statistics: Off
Mean & Std Dev
Samples: 2
High Ref: 90.0%
Mid Ref: 50.0%
Low Ref: 10.0%
