SAVE/RECALL
215
File Format/Utility
Image File Format
Format
*.bmp or *.png
Default Filename
DSxxxx.bmp/png
Contents
The display image is 800 by 480 pixels. The
background color can be inverted (Ink saver
function). Each image file is saved to the current
file path as a bitmap or PNG file.
Waveform File Format
Format
DSxxxx.lsf, CH1~CH4.lsf
The LSF file format efficiently stores waveforms.
This is the file format used for storing and recalling
all waveforms that are used with the GDS-2000E
series.
Filename
DSxxxx.lsf, CH1 ~ CH4.lsf
Waveform Type
CH1 ~ 4
Input channel signal
REF
Reference waveform
Math
Math operation result (page 68)
Storage Location
Wave1 ~
Wave20
Waveform files stored to the internal
memory. Stored waveforms can be
transferred to Ref. 1 ~ 4 to be viewed
on the display. (W1 ~ W20 waveforms
cannot be directly recalled on the
display).
