Probe Specifications
GTP-070B-4
Applicable to: GDS-2072E & GDS-2074E
Position x10
Attenuation Ratio
10:1
Bandwidth
DC to 70MHz
Input Resistance
10MΩ when used with oscilloscopes
with 1MΩ input
Input Capacitance
14.5pF to 17.5pF
Compensation Range
10pF to 35pF
Max. Input Voltage
≤600V DC + ACpk
Position x1
Attenuation Ratio
1:1
Bandwidth
DC to 10MHz
Input Resistance
1MΩ (oscilloscope input resistance)
Input Capacitance
85pF to 115pF
Max. Input Voltage
≤200V DC + ACpk
Operating Cond.
Temperature
-10°C to 50° C
Relative Humidity
≤85%
GTP-100B-4
Applicable to: GDS-2102E & GDS-2104E
Position X10
Attenuation Ratio
10:1
Bandwidth
DC to 100MHz
Input Resistance
10MΩ when used with oscilloscopes
with 1MΩ input.
Input Capacitance
14.5pF to 17.5pF
Compensation Range
5pF to 30pF
Max. Input Voltage
≤600V DC + ACpk
Position X1
Attenuation Ratio
1:1
Bandwidth
DC to 10MHz
Input Resistance
1MΩ (oscilloscope input resistance)
Input Capacitance
85pF to 115pF
Max. Input Voltage
≤200V DC + ACpk
Operating Cond.
Temperature
–10°C to 50° C
Relative Humidity
≤85%
