GDS-2000E Series User Manual
224
Save Image
Images can be saved either using the Save/Recall key or by using
the Hardcopy key. To save images using the Hardcopy key, see the
hardcopy section on page 246.
Panel Operation
1. To save to USB, connect a USB
drive to the front panel USB
port. If a USB drive is not
connected, images can still be
saved to the internal memory.
Front Panel
2V
2. Press the Save/Recall key from the
front panel.
Save/Recall
3. Press Save Image from the bottom
menu.
4. Press File Format to choose PNG or
BMP file types.
Range
DSxxxx.bmp, DSxxxx.png
5. Press Ink Saver to toggle Ink Saver
On or Off.
Ink Saver On
Ink Saver Off
