Page #274 background imageLoading...
Page #274 background image
GDS-2000E Series User Manual
274
GDS-2000E Specifications
The specifications apply when the GDS-2000E is powered on for at
least 30 minutes under +20°C~+30°C.
Model-specific
GDS-2072E
Channels
2 + Ext
Bandwidth
DC ~ 70MHz (3dB)
Rise Time
5ns
Bandwidth Limit
20MHz
GDS-2074E
Channels
4
Bandwidth
DC ~ 70MHz (3dB)
Rise Time
5ns
Bandwidth Limit
20MHz
GDS-2102E
Channels
2 + Ext
Bandwidth
DC ~ 100MHz (3dB)
Rise Time
3.5ns
Bandwidth Limit
20MHz
GDS-2104E
Channels
4
Bandwidth
DC ~ 100MHz (3dB)
Rise Time
3.5ns
Bandwidth Limit
20MHz
GDS-2202E
Channels
2 + Ext
Bandwidth
DC ~ 200MHz (3dB)
Rise Time
1.75ns
Bandwidth Limit
20MHz/100MHz
GDS-2204E
Channels
4
Bandwidth
DC ~ 200MHz (3dB)
Rise Time
1.75ns
Bandwidth Limit
20MHz/100MHz
