GW Instek GDS-2000E Series - Probe Compensation Frequency; QR Code Reader Function

CONFIGURATION
189
5. Make sure the date/time setting is correctly
reflected at the top of the display.
Probe Compensation Frequency
Background
The probe compensation
output can be set from
1kHz (default) to
200kHz, in steps of
1kHz.
2V
Compensation
output
Panel Operation/
Parameter
1. Press the Utility key.
Utility
2. Press Probe Comp. on the lower
menu.
3. Press Frequency and change the
frequency of the probe
compensation signal.
Default Frequency
4. Press Default to set the frequency
of the probe compensation signal
to 1kHz default.
QR Code Reader Function
Background
The QR Code reader function displays a number of
preset QR codes that link to useful websites.
