CONFIGURATION
89
Set the Number of Segments
Before the Segment function can be used, set the
trigger settings as appropriate for the signal you
wish to use. The number of segments that can be
used depends wholly on the record length. See
page 85 to set the record length.
1. Press the Acquire key.
2. Press Segments on the bottom
menu.
3. Press Select Segments and set the
number of segments from the side
menu.
1~29000 (record length
dependant)
Sets to the maximum number
The Select Segments icon is only available when
when Segments = OFF or when Segments is in the
STOP mode (see the section below).
To Next Page
