GW Instek GDS-2000E Series User Manual

CONFIGURATION
137
Save Event Table
4. To save the event table, press Save
Event Table. The Event table will be
saved to the current file path in a
CSV format. See page 140 for
details.
Use the variable knob to scroll through the
event table.
Example:
UART Event table
Time of trigger
Tx
Rx
Errors
Select cursor
Example:
I
2
C Event table
Time of trigger
Repeat Start
Address
Data at address
Missing Ack
Select cursor
