148
LIN
Local Interconnect Network
Trigger Mode
Auto (un-
triggered
roll)
The GDS-2000E generates an internal
trigger if there is no trigger event, to
make sure waveforms are constantly
updated regardless of trigger events.
Select this mode especially when
viewing rolling waveforms at slower
timebases.
Normal
The GDS-2000E acquires a waveform
only when a trigger event occurs.
Single
The GDS-2000E acquires a
waveform once when a
trigger event occurs, then
stops acquiring. Press the
Single key to acquire a
waveform again.
Single
Coupling
(Edge, Delay,
Timeout)
DC
DC coupling.
AC
AC coupling. Blocks DC components
from the trigger circuits.
HF reject
High frequency filter above 70kHz
LF reject
Low frequency filter below 70kHz
Reject noise
DC coupling with low sensitivity to
reject noise.
Slope
(Edge, Delay, Rise
& Fall)
Trigger on a rising edge.
Trigger on a falling edge.
Either. (either rising or falling edge)
(Edge, Delay, Rise & Fall trigger type
only)
