GW Instek GDS-2000E Series User Manual

CONFIGURATION
151
Trigger On
(Bus)
Selects the conditions for the bus triggers.
UART Bus
Tx Start Bit, Rx Start Bit, Tx End of
Packet, Rx End of Packet, Tx Data, Rx
Data, Tx Parity Error, Rx Parity Error
I
2
C
Start, Repeat Start, Stop, Missing Ack,
Address, Data, Address/Data
SPI
SS Active, MOSI, MISO, MOSI&MISO
CAN
Start of Frame, Type of Frame,
Identifier, Data, Id & Data, End of
Frame, Missing Ack, Bit Stuffing Err
LIN
Sync, Identifier, Data, Id & Data,
Wakeup Frame, Sleep Frame, Error
Threshold
(Pulse Runt)
Sets the upper threshold limit.
Sets the lower threshold limit.
Threshold
(Rise & Fall)
Sets the High threshold.
Sets the Low threshold.
Trigger When
(Timeout)
Stays High
Triggers when the input signal stays
high for a designated amount of time.
Stays Low
Triggers when the input signal stays
low for a designated amount of time.
Either
Triggers when the input signal stays
high or low for a designated amount
of time.
Timer
(Timeout)
4nS~10.0S
Sets the amount of time that a signal
must stay high or low for the timeout
trigger.
