GW Instek GDS-2000E Series User Manual

APPS
213
13. For the Video category mode, connect a probe
from CH1 on the DSO to the Video port on the
demo board. Connect the ground clip to the
GND port.
Video
FM
Digital
Ch1
Ch2 Ch3
Ch
X
1
0
X
1
Demo Board
Video Port
GNDVIDEO
Running the
Demo
14. After the demo board has been
setup, simply press Run from the
side panel.
The chosen signal from the demo board will
automatically be output and the DSO will be
automatically setup to trigger the demo signal.
