GDS-2000E Series
User Manual
22
Ground T
erm
inal
2
V
Accepts the DUT gr
ound lead for
common ground.
Probe
C
ompensation
Outputs
2V
The probe compensa
tion output
is
used for probe co
mpensation. It
also has an adjustable out
put
frequency.
By default this port
outputs a
2Vpp, square wave sig
nal at 1
kHz
for probe compensation.
Please see page
189
for details.
Power Switch
POWER
Used to turn the po
wer on/off.
: ON
: OFF
21
23
