GW Instek GSP-9300 User Manual

ADVANCED OPERATION
133
AM modulation
measurements
AM waveform
4. Press Setup[F2]>IF Bandwidth[F1] and set the
Intermediate frequency bandwidth.
 Set with adequate bandwidth to accommodate
spectrum contained in the carrier.
5. Press LPF[F2] to set the low pass filter
frequency, alternatively the frequency can be
set to bypass:
AM Signal Frequency (Hz)
Selectable bandwidth of LPF (Hz)
≥78,125
156,250
78,125
52,083
39,063
31,250
≥39,063
78,125
39,063
26,042
19,531
15,625
≥19,531
39,063
19,531
13,021
9,766
7,813
≥7,813
15,625
7,813
5,208
3,906
3,125
≥3,906
7,813
3,906
2,604
1,953
1,563
≥1,953
3,906
1,953
1,302
977
781
≥781
1,563
781
521
391
313
≥391
781
391
260
195
156
≥195
391
195
130
98
78
≥78
156
78
52
39
31
≥39
78
39
26
20
16
≥20
39
20
13
10
8
≥8
16
8
5
4
3
