Ref. Pos[F2]
Shifts the waveform X
number of grid
subdivisions.
Scale/Div[F3]
Sets the grid division
scale when Auto Scale is
Off.
Auto Scale[F4]
Toggles auto-scaling
on/off.
8. Press Deviation Axis[F6] to set deviation
(vertical) parameters:
Ref.Value[F1]
Offsets the reference
position (in frequency).
Ref.Pos[F2]
Sets the reference
position of the waveform
on a vertical grid
subdivision (1:10).
Scale/Div[F3]
Sets the vertical grid
division scale when
Auto Scale is Off.
Auto Scale[F4]
Toggles auto-scaling
on/off.
Operation:
trigger
configuration
9. Press More[F7]>Ext.Trigger [F1] to set the
triggering conditions:
Free Run[F1]
Disables the trigger, this
is the default setting.
Edge Slope[F2]
Sets the trigger to rising
or falling edge.
Trigger Mode[F3]
Sets the triggering mode:
Norm.: Normal trigger
Sgl.: Single trigger
Cont.: Continuously
trigger
