GW Instek GSP-9300 User Manual

GSP-9300 User Manual
228
Sequence Editor window
Main display
Start Edit/
Stop Edit icon
Sequence
function
menu
Add a Step
Up to 20 steps can be added to each sequence.
Each panel operation is recorded as a step.
After each panel operation is performed, press
the
Enter
key to record the step (in some cases
this is not necessary – check if the operation
appears in the sequence editor window).
In the following example the center frequency
and span are added as steps to a sequence:
1. Press
Frequency
>Center Freq[F1]>20MHz>
Enter
.
2. Press
Span
>Zero Span[F3]>
Enter
.
3. The two operations are added to the Sequence
Editor.
4. Press the
Sequence
key again to return to the
sequence function menu.
