GSP-9300 User Manual
250
File Types
Overview
The file types are listed in order as shown in the
File menu.
State
State data contains the state of the each of the
panel operations:
 Frequency
 Span
 Amplitude
 BW/AVG
 Sweep
 Trace
 Display
 Measure
 Limit Line
 Sequence
 Trigger
 Marker
 Marker
 Peak Search
 Preset
 System
Trace
Trace data contains the trace data in comma
separated values.
 Center frequency
 Span
 Resolution Bandwidth
 Video Bandwidth
 Reference Level
 Sweep Time
 Point number (trace data points)
Screen
Contains the JPEG file of the display (800X600)
Limit Line
The limit line data contains the following in
comma separated values:
 Point number
 Frequency value of point
 Magnitude of point
 Magnitude unit
