GETTING STARTED
25
Average
Indicates that the Average function
is active.
External Lock
Indicates that the system is now
locked and refers to the external
reference input signal
External Trigger
External trigger signal is being
used.
Math
Trace math is being used.
Sequence
Indicator
Shown when a sequence is running.
Sweep Indicator
Indicates that the sweep time is
manually set.
Tracking
generator
Indicates that the tracking generator
is turned on.
TG Normalization
Indicates that the tracking generator
has been normalized.
Wake-up clock
Indicates that the wake-up clock is
turned on.
USB
Indicates that a USB flash drive is
inserted into the front panel and is
recognized.
Micro SD
Indicates that a micro SD card is
inserted into the front panel and is
recognized.
