101
Procedure
1. Power off the server. For more information, see "Powering off the server."
2. Remove the server from the rack. For more information, see "Removing the server from a rack."
3. Remove the
access panel. For more information, see "Removing the access panel."
4. Disco
nnect cables from the PCIe Ethernet adapter.
5. Remove the PCIe Ethernet adapter. For more information, see "Replacing a riser card and a
PCIe modul
e."
6. Install a new PCIe Ethernet adapter. For more information, see "Installing riser cards and PCIe
module
s."
7. Connect cables for the PCIe Ethernet adapter.
8. Install the access panel. For more information, see "Installing the access panel."
9. Rack-mount the server. For more information, see "Rack-mounting the server."
10. Con
nect the power cord. For more information, see "Connecting the power cord."
11. Powe
r on the server. For more information, see "Powering on the server."
Verifying the replacement
Log in to HDM to verify that the PCIe Ethernet adapter is in a correct state. For more information, see
HDM online help.
Replacing a M.2 transfer module and a SATA M.2
SSD
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
To replace a M.2 transfer module and a SATA M.2 SSD:
1. Power off the server. For more information, see "Powering off the server."
2. Remove the server from the
rack. For more information, see "Removing the server from a rack."
3. Remove the
access panel. For more information, see "Removing the access panel."
4. Remove the
chassis air baffle. For more information, see "Removing air baffles."
5. Remove the f
an cage. For more information, see "Replacing the fan cage."
6. Remove the
security bezel, if any. For more information, see "Replacing the security bezel."
7. Remove the SATA M.2 SSD:
a. Remove the M.2 transfer module. To remove the module, disconnect the cable connected
to the M.2 transfer module. Then, remove the M.2 transfer module in the same way as
removing a SATA optical drive. For more information, see "Replacing the SATA optical
drive."
b. Remove the
screw that secures the SSD on the transfer module. Tilt the SSD by the
screw-side edges, and then pull the SSD out of the connector, as shown in Figure 136.
