157
UIS-Cell 3020 G3
Figure 198 Drive numbering
UIS-Cell 3030 G3
Figure 199 Drive numbering
UIS-Cell 3040 G3
Figure 200 Drive numbering
Drive LEDs
The server supports SAS and SATA drives, which are hot swappable. You can use the LEDs on a
drive to identify its status after it is connected to a storage controller.
Figure 201
shows the location of the LEDs on a drive. Table 25 describes the status of the LEDs.
Figure 201 Drive LEDs
(1) Fault/UID LED (2) Present/Active LED
