3. Install the removed processors and heatsinks. For more information, see "Installing
processors."
4. Install the removed DIMMs. For more information, see "Installing DIMMs."
5. Install the removed mLOM Ethernet adapter. For more information, see "Installing an mLOM
Ethernet ad
apter."
6. Install the removed Mezzanine storage controller. For more information, see "Installing a
Mezzani
ne storage controller and a power fail safeguard module."
7. Install the removed PCIe riser cards and PCIe modules. For more information, see "Installing
rise
r cards and PCIe modules."
8. Connect cables to the system board.
9. Install the fan cage. For more information, see "Replacing the fan cage."
10. Install air baff
les. For more information, see "Installing air baffles."
11. Install the access panel. For more information, see "Installing the access panel."
12. Install the removed power supplies. For more information, see "Installing power supplies."
13. Rack-mount the server. For more information, see "Rack-mounting the server."
14. Con
nect the power cord. For more information, see "Connecting the power cord."
15. Powe
r on the server. For more information, see "Powering on the server."
Verifying the replacement
Log in to HDM to verify that each part is operating correctly and no alert is generated. For more
information, see HDM online help.
Replacing the drive expander module
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Procedure
1. Power off the server. For more information, see "Powering off the server."
2. Remove the server from the rack. For more information, see "Removing the server from a rack."
3. Remove the
access panel. For more information, see "Removing the access panel."
4. Remove the
chassis air baffle if it hinders the replacement. For more information, see
"Removing air baffles."
5. Remove the fan cage if it hinders the replacement. For more information, see "Replacing the
fan cag
e."
6. Disconnect cables from the expander module.
7. Loosen the captive screws that secure the expander module, and pull the expander module to
disengage the pin holes from the guide pins. Then lift the module out of the chassis, as shown
in Figure 150.
