H3C UIS-Cell 3000 G3

140
Technical specifications
Item UIS-Cell 3010 G3 UIS-Cell 3020 G3 UIS-Cell 3030 G3 UIS-Cell 3040 G3
Dimensions
(H × W × D)
• Without a security bezel: 87.5 × 445.4 × 745.5 mm (3.44 × 17.54 × 29.35 in)
• With a security bezel: 87.5 × 445.4 × 768.45 mm (3.44 × 17.54 × 30.25 in)
Max. weight 23.58 kg (51.99 lb) 32.75 kg (72.20 lb) 32.65 kg (71.98 lb) 27.33 kg (60.25 lb)
Processors
2 × Intel Xeon Skylake-SP processors
(Up to 3.6 GHz base frequency, maximum 205 W power consumption, and 38.5 MB cache
per processor)
Memory
768 GB (maximum)
24 × DDR4 DIMMs
Max storage
• SAS drives: 1.2
TB*16 = 19.2
TB
• SATA drives:
3.84 TB*16 =
61.44 TB
• SAS drives: 1.2
TB*25 = 30 TB
• SATA drives:
3.84 TB*25 =
96 TB
• SAS drives: 6
TB*12 = 72 TB
• SATA drives: 8
TB*12 = 96 TB
• SAS drives: 6
TB*8 = 48 TB
• SATA drives: 8
TB*8 = 64 TB
Chipset Intel C62x Lewisburg chipset compatible with LBG-T SKU
GPU modules 3 (maximum) 3 (maximum) 3 (maximum) 3 (maximum)
Connectors
• 6 × USB connectors:
{ 5 × USB 3.0 connectors (one at the server front, two at the server rear, and two on
the system board)
{ 1 × USB 2.0 connector (provided by the left chassis ear with a USB 2.0 connector)
• 9 SATA connectors in total:
{ 1 × onboard mini-SAS connector (x8 SATA connectors)
{ 1 × onboard x1 SATA connector
• 1 × RJ-45 HDM dedicated port at the server rear
• 2 × VGA connectors (one at the server rear and one at the server front)
• 1 × BIOS serial port at the server rear
• 1 × mLOM Ethernet adapter connector (NCSI-capable)
Expansion
slots
9 × PCIe 3.0 modules (eight PCIe modules and one mezzanine storage controller)
Optical drives
• External USB
optical drives
• Internal SATA
optical drive
The internal SATA
optical drive is
available only when
the optical drive
enablement option
is installed.
External USB
optical drives
External USB
optical drives
External USB
optical drives
Fans
A maximum of six fans
The chassis is shipped with one fan. Each processor has two fans.
Power
supplies
2 × hot-swappable power supplies in redundancy
Slide rail kit 2U standard slide rail kit
Security bezel 2U security bezel
