H3C UIS-Cell 3000 G3

162
Riser cards for riser connector 3
UIS-RC-FHHL-2U-G3-F
Item Specifications
PCIe riser connector Connector 3
PCIe slots
• Slot 7: PCIe3.0 ×16 (16, 8, 4, 2, 1)
• Slot 8: PCIe3.0 ×8 (8, 4, 2, 1)
NOTE:
The numbers in parentheses represent link widths.
Form factors of PCIe modules FHHL
Maximum power supplied per PCIe slot 75 W
Figure 204 PCIe slots on the UIS-RC-FHHL-2U-G3-F riser card
(1) PCIe slot 7 (2) PCIe slot 8
UIS-RC-2*LP-2U-G3-F
Item Specifications
PCIe riser connector Connector 3
PCIe slots
• Slot 7: PCIe3.0 ×16 (16, 8, 4, 2, 1)
• Slot 8: PCIe3.0 ×8 (8, 4, 2, 1)
NOTE:
The numbers in parentheses represent link widths.
Form factors of PCIe modules LP
Maximum power supplied per PCIe slot 75 W
