Figure 126 Removing the UIS-RC-GPU/FHHL-2U-G3-F riser card
6. Remove the screw that secures the PCIe module, and then pull the PCIe module out of the slot,
as shown in Figure 127.
Figure 127
Removing a PCIe module
7. Install a new riser card and PCIe module. For more information, see "Installing riser cards and
PCIe modules."
8. Install the access panel. For more information, see "Installing the access panel."
9. Mount the server in the rack. For more information, see "Installing the server."
10. Connect the power cord. For more information, see "Connecting the power cord."
11. Powe
r on the server. For more information, see "Powering on the server."
Replacing the storage controller
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal modules to cool before
touching them.
Guidelines
To replace the storage controller with a controller of a different model, reconfigure RAID after the
replacement. For more information, see the storage controller user guide for the server.
