H3C UIS-Cell 3000 G3

154
Component UIS-Cell 3010 G3 UIS-Cell 3020 G3 UIS-Cell 3030 G3 UIS-Cell 3040 G3
mLOM
Ethernet
adapter
• 4-port GE copper port mLOM Ethernet adapter-360T L3
• 2-port 10GE copper port mLOM Ethernet adapter-560T L2
• 2-port 10GE fiber port mLOM Ethernet adapter (SFP+)-560F L2
PCIe Ethernet
adapter
• UIS-NIC-GE-4P-360T-B2: 4-port GE copper port Ethernet adapter-360T B2
• UIS-CNA-10GE-2P-560F-B2: 2-port 10-GE fiber port Ethernet adapter (SFP+)-560F
B2
• UIS-NIC-10GE-2P-530F-B2: 2-port 10-GE fiber port Ethernet adapter (SFP+)-530F
B2
HBA
• UIS-FC-HBA-QLE2690-16Gb-1P: 1-port 16Gb fiber channel HBA (with one SFP+
transceiver module)
• UIS-FC-HBA-QLE2560-8Gb-1P: 1-port 8Gb fiber channel HBA (with one SFP+
transceiver module)
• UIS-FC-HBA-QLE2562-8Gb-2P: 2-port 8Gb fiber channel HBA (with two SFP+
transceiver modules)
• UIS-FC-HBA-QLE2692-16Gb-2P: 2-port 16Gb fiber channel HBA (with two SFP+
transceiver modules)
GPU module
UIS-GPU-M60-1
UIS-GPU-M60-2-F
UIS-GPU-P40
UIS-GPU-P4
UIS-GPU-M10
UIS-GPU-M10-1-F
Internal
optical drive
• UIS-DVD-RW-
Mobile-USB-F:
USB 2.0 optical
drive
• UIS-DVD-RW-
SATA-9.5MM-F
: 9.5mm SATA
DVD-RW
optical drive
• UIS-DVD-ROM
-SATA-9.5MM-
F: 9.5mm SATA
DVD-ROM
optical drive
Not supported Not supported Not supported
Power supply
• PSR550-12A-F2: 550W AC power supply
• PSR800-12A-F2: 800W AC power supply
• PSR800-12AHD-F1: 800W high-voltage DC pow
• PSR1200-12A-F2: 1200W AC power supply
• PSR1600-12A-F: 1600W AC power supply
Secuirty bezel M2U security bezel
DIMMs
The server provides 6 DIMM channels per processor, 12 channels in total. Each DIMM channel has
two DIMM slots and supports a maximum of eight ranks. For the physical layout of DIMM slots, see
"DIMM slots."
