H3C UIS-Cell 3000 G3

65
b. Insert one end of the supercapacitor into the holder, pull the clip on the holder, insert the
other end of the supercapacitor into the holder, and then release the clip, as shown in Figure
88.
NOTE:
If the power cords of the front drives backplane hinder supercapacitor installation, remove
the cables before installation and reconnect the cables after installation.
c. Connect the flash card on the storage controller to the supercapacitor. For more information,
see "Connecting the flash card on a standard storage controller."
9. Con
nect the drive data cables to the standard storage controller. For more information, see
"UIS-Cell 3010 G3 server."
10. Install the removed fan cage. For more information, see "Installing fans."
11. Install the removed air baffles. For more information, see "Installing air baffles."
12. Install the access panel. For more information, see "Installing the access panel."
13. Rack-mount the server. For more information, see "Rack-mounting the server."
14. Con
nect the power cord. For more information, see "Connecting the power cord."
15. Powe
r on the server. For more information, see "Powering on the server."
Verifying the installation
Log in to HDM to verify that the standard storage controller, flash card, and supercapacitor are
operating correctly. For more information, see HDM online help.
Installing GPU modules
Guidelines
For the GPU modules available for the server, see "GPU modules."
A riser card is required when you install a GPU module. See Table 7
for the available riser cards for
GPU modules and the installation position of GPU modules on a riser card.
Table 7 GPU module and riser card compatibility
Riser card
location
Riser card model
PCIe slots on the
riser card
Available GPU modules
PCIe riser connector
1 or PCIe Riser
connector 2
UIS-RC-GPU/FHHL-2U
-G3-F1
2/5
• UIS-GPU-M60-1
• UIS-GPU-M60-2-F
• UIS-GPU-P4
• UIS-GPU-P40
• UIS-GPU-M10
• UIS-GPU-M10-1-F
3/6 N/A
PCIe riser connector
3
UIS-RC-GPU/FHHL-2U
-G3-F
7
• UIS-GPU-M60-1
• UIS-GPU-M60-2-F
• UIS-GPU-P4
• UIS-GPU-P40
• UIS-GPU-M10
• UIS-GPU-M10-1-F
8 N/A
