96-8100 1-15-96
194
PARAMETERS
SERVICE
MANUAL
VF-SERIES
Parameter 221 MAX TIME NO DISPLAY
The maximum time (in 1/50 sec.) between screen updates.
Parameter 222 ROTARY AXIS INCRMNT
For Horizontal mills only. This parameter sets the degrees of rotation of the A-
axis at an M36 or Pallet Rotate.
Parameter 223 AIR TC DOOR DELAY
For Horizontal mills only. This parameter sets the delay to open the tool changer
door (in milliseconds). If the tool changer does not have a pneumatic door, this
parameter is set to zero.
Parameter 224 ROT AXIS ZERO OFSET
This parameter shifts the zero point of A for a wheel fixture or tombstone.
Parameter 225 MAX ROT AXIS ALLOW
For Horizontal mills with a wheel fixture only. This parameter sets the maximum
rotation (in degrees) allowed before stopping at front door.
Parameter 226 RESERVED
Parameter 227 FLOPPY DIR NAME
This parameter sets the program numbers to store in the floppy directory.
Parameter 228 QUICKCODE FILE
This parameter set the program numbers to store in the Quickcode definition.
Parameter 229 X LEAD COMP 10E9
This parameter sets the X-axis lead screw compensation signed parts per
billion.
Parameter 230 Y LEAD COMP 10E9
This parameter sets the Y-axis lead screw compensation signed parts per
billion.
Parameter 231 Z LEAD COMP 10E9
This parameter sets the Z-axis lead screw compensation signed parts per
billion.
Parameter 232 A LEAD COMP 10E9
This parameter sets the A-axis lead screw compensation signed parts per
billion.
Parameter 233 B LEAD COMP 10E9
This parameter sets the B-axis lead screw compensation signed parts per
billion.
Parameter 235 TSC PISTON SEAT
With the TSC option, the amount of time given for the piston to seat during
system start-up. The default is 1500 milliseconds.
