1-15-96 96-8100
HAAS AUTOMATION, INC.
29
TABLE OF CONTENTS
ALARMS
SERVICE
MANUAL
VF-SERIES
170 Phase Loss L1-L2 Problem with incoming line voltage between legs L1 and L2. This usually indicates that there
was a transient loss of input power to the machine.
171 Phase Loss L2-L3 Problem with incoming line voltage between legs L2 and L3.
172 Phase Loss L3-L1 Problem with incoming line voltage between legs L3 and L1.
173 Spindle Ref The Z channel pulse from the spindle encoder is missing for hard tapping
Signal Missing synchronization.
174 Tool Load Exceeded The tool load monitor option is selected and the maximum load for a tool
was exceeded in a feed. This alarm can only occur if the tool load monitor function is installed
in your machine.
175 Ground Fault Detected A ground fault condition was detected in the 115V AC supply. This can be caused by a short
to ground in any of the servo motors, the tool change motors, the fans, or the oil pump.
176 Over heat Shutdown An overheat condition persisted for 4.5 minutes and caused an automatic shutdown.
177 Over voltage Shutdown An overvoltage condition persisted for 4.5 minutes and caused an automatic shutdown.
178 Divide by Zero Software Error; Call your dealer.
179 Low Pressure Spindle coolant oil is low or low pressure condition in lines.
Transmission Oil
180 Tool Arm Rotation Fault For Side Mount Tool Changer, the tool exchange operation did not sense the 180 degree
rotation switch.
181 Tool Pot Position Fault For Side Mount Tool Changer, the tool pot positioning mechanism is not working.
182 X Cable Fault Cable from X-axis encoder does not have valid differential signals.
183 Y Cable Fault Same as 182.
184 Z Cable Fault Same as 182.
185 A Cable Fault Same as 182.
186 Spindle Not Turning Status from spindle drive indicates error.
187 B Servo Error Too Large Same as 103.
188 B Servo Overload Same as 108.
189 B Motor Overheat Same as 135.
190 B Motor Z Fault Same as 139.
191 B Limit Switch Same as 148.
