Page #37 background imageLoading...
Page #37 background image
1-15-96 96-8100
HAAS AUTOMATION, INC.
37
TABLE OF CONTENTS
ALARMS
SERVICE
MANUAL
VF-SERIES
394 B Over Travel Range Same as 316.
398 Aux Axis Servo OffAux. axis servo shut off due to a fault.
403 RS-232 Too Many Progs Cannot have more than 100 programs in memory.
404 RS-232 No Program Need name in programs when receiving ALL; otherwise has no way to
Name store them.
405 RS-232 Illegal Prog Check files being loaded. Program name must be Onnnn and must be
Name at beginning of a block.
406 RS-232 Missing Code A receive found bad data. Check your program. The program will be
stored but the bad data is turned into a comment.
407 RS-232 Invalid Code Check your program. The program will be stored but the bad data is turned into a comment.
408 RS-232 Number Range Check your program. The program will be stored but the bad data is
Error turned into a comment.
409 RS-232 Invalid N Code Bad Parameter or Setting data. User was loading settings or parameters and something was
wrong with the data.
410 RS-232 Invalid V Code Bad parameter or setting data. User was loading settings or parameters and something was
wrong with the data.
411 RS-232 Empty Program Check your program. Between % and % there was no program found.
412 RS-232 Unexpected Check Your Program. An ASCII EOF code was found in the input data
End of Input before program receive was complete. This is a decimal code 26.
413 RS-232 Insufficient Program received doesnt fit. Check the space available in the LIST PROG
Memory mode and possibly delete some programs.
414 RS-232 Buffer Overflow Data sent too fast to CNC. This alarm is not normally possible as this control can keep up with
even 38400 bits per second.
415 RS-232 Overrun Data sent too fast to CNC. This alarm is not normally possible as this control can keep up with
as much as 38400 bits per second.
416 RS-232 Parity Error Data received by CNC has bad parity. Check parity settings, number of
data bits and speed. Also check your wiring.
417 RS-232 Framing Error Data received was garbled and proper framing bits were not found. One or more characters of
the data will be lost. Check parity settings, number of data bits and speed.
418 RS-232 Break Break condition while receiving. The sending device set the line to a break condition. This
might also be caused by a simple break in the cable.
