HIKVISION DS-K1T804A Series - Device Wiring; Terminal Description

No. Descripon
5
Deleng Key: Press the key to delete the
leers or numbers one by one in the
textbox.
6
Eding Key: Hold the key to shi among
numbers/lowercases, numbers/
uppercases and symbols.
4 Device Wiring
4.1 Terminal Descripon
The terminal diagram are as follows.
Figure 4-1 Terminal Diagram
4
