8.4 Function Specifications
154
Other Functions
Wiring configuration
diagram display
Wiring configuration diagram display
Phase (input terminal)
color selection
Displays wiring configurations, numerical values, waveforms and
vectors with selected phase colors
Battery check
Remaining battery charge
Display hold
Display Hold on/off (VIEW screen only)
Warning indicators
Crest factor out-of-range, frequency selection error, internal memory
overwrite error
Numerical over-range
display
“- - - - -” (Numerical display when 130% of voltage or current range is
exceeded)
Key-lock
Enable/disable by holding [ESC] key for 3 seconds
Disables all key operations except the power switch
Help messages
Displays a description of the selected item on the SYSTEM screen
Memory Backup Operation
Savable data
Measurement data and image data
Data management
function
Amount of recorded data, remaining recording capacity displays
Data deletion
Recording format
Settings data: Binary format
Image data: BMP format
Measurement data: Binary format
