Rear Panel
Battery Compartment
The supplied Model 9459 Bat-
tery Pack installs here. (p. 39)
Serial No.
Shows the serial No..
Do not remove this label, as it is
required for product support.
Stand
Opening and closing the stand
Do not apply heavy downward pressure with the
stand extended. The stand could be damaged.
Opening the stand
1. Pull the stand out until it clicks.
2. Push the stand holder in until it clicks in the
hook on the rear cover.
Closing the stand
Return the stand holder to its original position,
and close the stand until it clicks.
Click
Click
Battery information
This is accessible by opening the
stand.
Hook
Stand
1
2
To Next Page
