Hioki 3560 - Chapter 8 GP-IB Interface (Option)

101
────────────────────────────────────────────────────
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
SH1
All source handshake functions
AH
1
All accepter handshake functions
T6
Basic talk functions
Serial poll function
Talk-only mode is not provided.
The talker cancellation function with MLA (My Listen Address) is provided
.
L4
Basic listener function
Listen-only mode is not provided.
The listener cancellation function with MTA (My Talk Address) is provided
.
SR1
All service request functions
RL1
All remote/local functions
PP0
Parallel polling is not provided.
DC1
All device clear functions
DT1
All device trigger functions
C0
The controller function is not provided.
Chapter
8
GP-IB Interface (Optio
n)
Except for the power switch, all instrument functions can be performed
by remote control through the optional GP-IB interface. The RS-232C
and optional GP-IB interfaces may not be used simultaneously. (That is,
only one interface may be used at any one given time.) For more
information on selecting between the RS-232C or GP-IB interface, see the
section that describes setting the RS-232C interface. For more
information on selecting between the RS-232C or GP-IB interface, see the
section that describes Section 8.2 "Operating.Procedure (GP-IB)." For
more information on mounting the 9588 GP-IB interface, see Chapter 4
"Measurement Procedure."
Applicable standard: IEEE-488.1 1987
Reference standard: IEEE-488.2 1987
If the output queue is full, the 9588 issues a query error to clear it. The
9588 does not support output queue clear and query error output
functions in the deadlock state, as defined in the IEEE-488.2 standard.
(Deadlock state: Both input buffer and output queue are full, halting
further data processing.)
■ Connector
Use a 24-pin connector compatible with the IEEE-488 bus. Multiple
standard bus cables may be used.
■ Interface function
See the interface function table.
Applicable code: ASCII code
