Hioki 3560 - Common Command Messages

67
────────────────────────────────────────────────────
7.4 Message Reference
────────────────────────────────────────────────────
Synta
x
*CLS
Synta
x
*ESE data
dat
a
0 to 255 (Numerical value data)
Exampl
e
Transmission
*ESE 36
CME and QYE of the standard
event status enable register are
both set to "1."
Synta
x
*ESE?
Respons
e
synta
x
(If headers are ON)
*ESE data
(If headers are OFF)
data
Exampl
e
(If headers are OFF)
Transmission
*ESE?
Response
36
F
unctio
n
This instruction clears the event
registers and the bits of the status
byte register associated with that
register (SESR, STB).
Not
e
This has no effect upon the output
queue, the various enable registers,
or bit 4 (the MAV bit) of the status
byte register.
F
unctio
n
This command sets the available
patterns of the standard event
status register (SESR) to the
standard event status enable
register (SESER).
Note
s
When the power is turned on, the
data is reinitialized to 0.
F
unctio
n
The contents of SESER are returne
d
as a NR1 value (0 to 255).
7
.4.1 Common Command Messages
*CLS
■ Clears the status byte register and the event registers.
*ESE
■ Sets the standard event status enable register.
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
PON URQ CME EXE DDE QYE RQC OPC
Standard event status enable resister (SESER)
*ESE?
■ Queries out and clears the contents of the standard event status register (SESR).
