Hioki 3560 - Measurement Range

9
────────────────────────────────────────────────────
2.2 Measurement Range
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Range
Maximum
indication
Resolution
Measuremen
t
current
Accuracy
(6 months)
Accuracy
(1 year)
30 mΩ 31.000 mΩ 1 μΩ 7.4 mA ±0.5%rdgt.
±8 dgt.
(3 dgt.)
±0.7%rdgt.
±8 dgt.
(3 dgt.)
300 mΩ 310.00 mΩ 10 μΩ 1mA
3 Ω 3.1000 Ω 100 μΩ 100 μA
30 Ω 31.000 Ω 1 ｍΩ 10 μA
300 Ω 310.00 Ω 10 ｍΩ 5 μA
3kΩ 3.1000 kΩ 100 ｍΩ 1.5 μA
Range
Maximum
indication
Resolution
Measuremen
t
current
Accuracy
(6 months)
Accuracy
(1 year)
30 mΩ 31.00 mΩ 10 μΩ 7.4 mA ±0.5%rdgt.
±8 dgt.
±0.7%rdgt.
±8 dgt.
300 mΩ 310.0 mΩ 100 μΩ 1mA ±0.5%rdgt.
±6 dgt.
±0.7%rdgt.
±6 dgt.
3 Ω 3.100 Ω 1 ｍΩ 100 μA
30 Ω 31.00 Ω 10 ｍΩ 10 μA
300 Ω 310.0 Ω 100 ｍΩ 5 μA
3kΩ 3.100 kΩ 1 Ω 1.5 μA
Range
(Ｖ)
Maximum
indication
(Ｖ)
Measuremen
t
current
(Ｖ)
Accuracy
(6 months)
Accuracy
(1 year)
5 ±5.0000 100 μ ±0.05%rdgt.±5
dgt.(3dgt.)【5 dgt.】
±0.07%rdgt.±5
dgt.(3dgt.)【5 dgt.】
50 ±50.000 1 ｍ
2
.2 Measurement Range
■ Resistance measurement
Sampling rate: SLOW, MEDIUM
Temperature coefficient: (±0.05%rdg.±0.8 dgt.)/℃
*
If the sampling rate is set to MEDIUM, add ( ) to the digit accuracy
error.
Sampling rate: FAST
Temperature coefficient: 30 mΩrange (±0.05%rdg.±0.8 dgt.)/℃
: the other range (±0.05%rdg.±0.6 dgt.)/℃
Measurement current accuracy: ±10%
Measurement current frequency Accuracy: 1 kHz±0.2 Hz
■ Voltage measurement
Sampling rate: SLOW, MEDIUM, FAST
Temperature coefficient: (±0.005%rdg.±0.5 dgt.)/℃
*
If the sampling rate is set to MEDIUM, add ( ) to the digit accuracy
error.
*
If the sampling rate is set to FAST, add【】to the digit accuracy error.
