Chapter
6
External Control Terminal an
d
External Output Termina
l
The 3560 is provided with external control and output terminals and
supports the RS-232C interface and the optional GP-IB interface
connector and printer interface. The external control terminal permits
use of the measurement trigger, comparator trigger, printer trigger, and
zero-adjust, comparator selection functions.
Results of comparator operation and signals indicating abnormal
measurements and end of measurement are output from the external
output terminal. Use these functions to establish a measurement
sequence for the line.
