Hioki 3560 - 9287-10 CLIP TYPE LEAD (Option); 9452 Clip Type Lead

137
────────────────────────────────────────────────────
11.4 Options
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
1
1
12
13
14
15
1
1.4.4 9287-10 CLIP TYPE LEAD (Option)
150 mm
840 mm
The side with "V" mark is SENSE
.
1
1.4.5 9452 CLIP TYPE LEAD
200 mm
800 mm
Clip-type lead supplied with the 3560
Distance between the connector and the branch: approx. 150 mm
Distance between the branch and the probe end: approx. 840 mm
The 9452 CLIP TYPE LEAD has a bill-like nose, designed to ensure four-
terminal measurement even with objects having small contact areas, such
as relay terminals and connectors.
Distance between the connector and the branch: approx. 800 mm
Distance between the branch and the probe end: approx. 200 mm
