Hioki 3560 - 9453 Four Terminal Lead; 9455 Pin Type Lead

138
────────────────────────────────────────────────────
11.4 Options
────────────────────────────────────────────────────
1
1.4.6 9453 FOUR TERMINAL LEAD
300 mm
800 mm
1
1.4.7 9455 PIN TYPE LEAD
250 mm
400 mm
This is a four-terminal lead whose SOURCE terminal forms a covered
clip and whose SENSE terminal forms a measurement lead probe. The
9453 FOUR TERMINAL LEAD should be used to measure the pattern
resistance of the printed boards and the red and black SOURCE/SENSE
terminals separately.
Distance between the connector and the branch: approx. 800 mm
Distance between the branch and the probe end: approx. 300 mm
The nose has a four-terminal structure specifically designed for
examination of lifted IC leads on printed boards. This 9455 PIN TYPE
LEAD is capable of accurate resistance measurements even with small
objects.
Distance between the connector and the branch: approx. 400 mm
Distance between the branch and the probe end: approx. 250 mm
