2.1 General Specifications
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Measurement method Resistance AC four-terminal method
A/D method Σ-Δ method with sample hold function
Sampling rate Rated supply frequency:
50 Hz FAST 50 samples/sec 20.0 ms
MEDIUM 6.25 samples/sec 160 ms
SLOW 1.56 samples/sec 640 ms
60 Hz FAST 60 samples/sec 16.7 ms
MEDIUM 7.52 samples/sec 133 ms
SLOW 1.88 samples/sec 533 ms
Response time
（When a non-inductive
resistance is measured）
Rated supply frequency:
50 Hz FAST 100 ms
MEDIUM 800 ms
SLOW 1.92 s
60 Hz FAST 84 ms
MEDIUM 667 ms
SLOW 1.60 s
Response time may be determined by the measured object.
Open-circuit terminal
voltage
20 mVp max. (When limiter is ON）
Input overflow "OF" display
Current abnormality "-----" display
Comparator mode switch Switchable between AUTO and MANU
Comparator number 30 sets
Comparator buzzer [Resistance measurement mode]:
The buzzer sounds if the comparator results is Hi,Lo or IN.
[Resistance and voltage measurement mode]:
The buzzer sounds if the comparator results is PASS or FAIL.
Hold function Holds the display value.
Zero adjust function Revision of induced voltage in circuits and measurement leads.
Zero clear function Restores zero-adjust data to default values.
View function Displays both the measured value and comparator setting.
Buzzer function Turns the buzzer on or off while using the comparator.
Broken SENSE line
detection
Detects a broken SENSE line.
