4.4 Zero Adjust
────────────────────────────────────────────────────
Contacts with SENSE
945
3
9287-1
0
946
7
945
2
946
5
Right connectio
n
Wrong connectio
n
Contacts with SOURCE
Distance between battery terminals to be measured
946
1
Perform zero adjustment with the
a
lligator clips placed attached to th
e
o
utside of the unit and the lead rod o
n
the inside.
Bring the "V" marks together
at the same position.
Right connectio
n
Wrong connectio
n
OK
NG
4
.4 Zero Adjust
For accurate measurements, zero-adjust needs to be performed before
measurement. Zero-adjust is also available with the EXT.I/O terminal.
For more information on the EXT.I/O terminal, see Section 6.3.1
"External Control Terminal"
1. Connect the leads as shown below.
2. When the value observed in the display stabilizes, press the
0ADJ key.
3. After zero-adjust is completed, the system returns to measurement
mode.
