Hioki 3560 - Changing the Comparator Number

37
────────────────────────────────────────────────────
5.4 Changing the Comparator Number
────────────────────────────────────────────────────
The comparator number blinks
.
NOTE
5
.4 Changing the Comparator Number
Change the comparator number using the procedure shown below. For
information on using the comparator, see Section 5.5 "Switching On/Off
the Comparator."
1. Press the
COMP No. key to display the
comparator number setup screen. The
comparator number on the screen will flash.
2. Use the
+, keys to select a desired comparator
number in the range 01 to 30.
3. Press the
ENTER key to activate the
measurement mode associated with the setting
determined by the selected comparator number.
･ The comparator number set is saved when the instrument is shut down.
･ The comparator number can be changed even in View mode. For more
information on view function, see Section 5.6 "Checking the Comparator
Conditions (View)"
