135
────────────────────────────────────────────────────
11.3 Troubleshooting
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
1
12
13
14
15
Symptom Cause Follow-up
Display is not lit when
the powerswitch is
turned on.
Power cord is not correctly
connected.
Connect the power cord correctly.
See section 3.2 " Connecting the
Power Cord."
The power-supply voltage is
not consistent with the value
indicated on the 3560.
Use the power-supply voltage
indicated by the 3560.
The measured value is
not displayed.
Measurement values
are wrong.
Leads are not correctly
connected.
Connect leads correctly.
Leads are broken. Replace with a new cord.
A measurement object having
a large reactance is
measured.
Attempt to measure an object
having a small reactance.
Power supply frequency is no
correctly set.
Set the power supply frequency
correctly. See Section 3.5 "Setting
the Power Supply Frequency."
The preheating time is short. Ensure that sufficient preheating
time is provided prior to
measurement.
See Section 3.4 "Powering On/Off."
ERR
8 is displayed
continuously.
The EEPROM of the 3560 is faulty.
See Section 11.1 "Message Code
Table."
The resistance/voltage range
is not appropriate.
Select a range suitable for the
measurement object.
See Section 4.2 "Setting the
Measurement Range."
The key operation is
rejected.
Key lock is active. Cancel the key lock. See Section
4.3.7 "Key Lock."
Remote mode is active. Cancel the remote mode.
See Section 4.3.8 "Local."
Key lock can not be
cancelled.
Remote can not be
cancelled.
LLO is executed by GP-IB. Execute GTL (go to local) by GP-IB.
See Section 8.2 "Operating
Procedure (GP-IB)."
The external control
terminals (COMP0 to
COMP4) are selected.
Cancel selection of the external
control terminals (COMP0 to
COMP4).
See Section 6.3.1 "External Control
Terminal."
1.3 Troubleshooting
If damage is suspected, check the "Troubleshooting" section before
contacting your dealer or Hioki representative.
When sending the instrument for repair, pack carefully to prevent
damage in transit. Include cushioning material so the instrument cannot
move within the package. Be sure to include details of the problem. Hioki
cannot be responsible for damage that occurs during shipment.
