Hioki 3560 - Chapter 7 RS-232 C Interface

53
────────────────────────────────────────────────────
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Transmission mode
Start-stop synchronous, full duplex
Transfer rate
9600 bps（SPEED 9600 BPS）
Data bit length
8 bit（BIT 8）
Stop bit
1 bit（STOP 1）
Parity bit
None（PARITY NO）
Delimiter
CR+LF
Hand shake
Hardware
XON/XOFF
Not used（XON/XOFF OFF）
Connector
（D-sub9 Pin male #4-40 set square bolts)
DESP-JB9P (Japan Avionics)
Chapter
7
RS-232C Interfac
e
Except for the power switch, all instrument functions can be performed
by remote control through the RS-232C interface. The RS-232C and
optional GP-IB interfaces may not be used simultaneously. (That is, only
one interface may be used at any one given time.) For more information,
see Section 7.2 "Operating Procedure (RS-232C)."
■ Specifications
