2.1 General Specifications
────────────────────────────────────────────────────
External control terminals [CMOS input]
Measurement trigger（TRIG）, Comparator trigger（MANU）,
Printer（PRINT）, Zero-adjustment（0ADJ）, Digital ground
（GND）, Comparator number selection（COMP0 to COMP4）,
External power supply terminal（EXT.DCV）
External output terminals [Open collector output] (35 VDC max, 50 mA max.)
Comparator results (Hi (FAIL), IN (PASS), Lo (FAIL))*
End-of-output conversion signals (EOC) Measurement
irregularity signal (NG), Digital ground (GND)
*: Words in parentheses indicate output in resistance and
voltage measurement mode.
RS-232C I/F Standard
GP-IB I/F Option
Printer I/F Option, Centronics (can be connected the 9203 DIGITAL PRINTER
Operating temperature an
humidity range
0to40℃ (32 to 104ﾟF),
80%RH or less (no condensing)
Storage temperature and
humidity rage
10 to 50℃ (14 to 122ﾟF
), 80%RH or less (no condensing)
Operating temperature and humidity for
guaranteed accuracy
Period of guaranteed accuracy
23±5℃ (73±9ﾟF),
80%RH or less (no condensing)
1 year
Location for use Indoor, altitude up to 2000 m (6566 feet)
Rated supply voltage 100 V /110 V /120 V /200 V /220 V /240 V AC
(A voltage variation of ±10% is considered for the rated power
supply voltage.), Rated supply frequency: 50/60 Hz
Maximum rated power 30 VA
Maximum input voltage 60 VDC max (AC voltage cannot be input.)
Dielectric strength 2.3 kVrms for 1 minute / between power supply line (L,N) and
the Protective ground terminal
(dielectric strength measured within the inlet)
Dimensions 215W×80H×320D mm(8.46"W×3.15"H×12.6"D) approx.
(excluding protrusions)
Mass 2.1 kg (74.1 oz) approx.（not including options）
Accessories 9287-10 CLIP TYPE LEAD, Instruction manual,
Basic Instructions, Power cord
Options 9455 PIN TYPE LEAD
9461 PIN TYPE LEAD
9467 LARGE CLIP TYPE LEAD
9452 CLIP TYPE LEAD
9453 FOUR TERMINAL LEAD
9466 REMOTE CONTROL SWITCH
9454 ZERO ADJUSTMENT BOARD
9588 GP-IB INTERFACE
9151-02 GP-IB CONNECTOR CABLE (2 m)
9151-04 GP-IB CONNECTOR CABLE (4 m)
9589 PRINTER INTERFACE
9203 DIGITAL PRINTER
9425 CONNECTION CABLE
(for connecting the 3560 to the 9203/2-meters)
9233 RECORDING PAPER (for the 9203/10meters, 10rolls )
Applicable standards EMC: EN 61326
EN 61000-3-2
EN 61000-3-3
Safety: EN 61010
Pollution degree: level 2
Effect of radiated radio-frequency electromagnetic field: 4% f.s. at
3V/m (resistance measurement)
Effect of conducted radio-frequency electromagnetic field: 15% f.s.
at 3V (resistance measurement)
