22
────────────────────────────────────────────────────
4.3 Advanced Setting
────────────────────────────────────────────────────
9466
Spiral tube (small)
Spiral tube (large)
NOTE
■ 9466 REMOTE CONTROL SWITCH
The 9465 PIN TYPE LEAD and 9466 REMOTE CONTROL SWITCH can
be combined as shown below. (The 9455 PIN TYPE LEAD and 9461 PIN
TYPE LEAD can be also combined with the 9466.)
Connect the switch to the probe of the lead, and join the two cables using
the supplied spiral tube.
･ Do not insert or remove the mini-plug while the lead is connected to the
batteries. Before replacing the plug, always remove the lead from the
batteries.
･ If the spiral tube has a sharp edge at the end, round it with scissors to
prevent possible injury.
