Hioki 3560 - Page 4

4.3.5 Voltage Limiter 24
4.3.6 Zero Clear
24
4.3.7 Key Lock
25
4.3.8 Local 25
4.4 Zero Adjust 26
4.5 Starting Measurement 28
Chapter 5 Comparator Function 31
5.1 Resistance Measurement Mode
32
5.2 Resistance and Voltage Measurement Mode 34
5.3 Selecting the AUTO/MANU Comparator Mode 36
5.4 Changing the Comparator Number 37
5.5 Switching On/Off the Comparator 38
5.6 Checking the Comparator Conditions (View) 39
5.6.1 View in Comparator of Resistance
Measurement Mode Setting 39
5.6.2 View in Comparator of Resistance and
Voltage Measurement Mode Setting 40
Chapter 6 External Control Terminal and External
Output Terminal 41
6.1 Terminals and Signals
42
6.2 Connection Method 44
6.3 Measurement by External Control Terminal and
External Output Terminal
45
6.3.1 External Control Terminal (Input Signal)
45
6.3.2 External Output Terminal (Output Signal) 46
6.3.3 Timing Chart 47
6.3.4 Internal Circuit Configuration (Input/Output) 51
Chapter 7 RS-232C Interface 53
7.1 Connection to Computer (RS-232C)
54
7.2 Operating Procedure (RS-232C) 55
7.2.1 Setting the RS-232C
55
7.2.2 Communication Methods by the RS-232C 55
7.2.3 Program Messages 56
7.2.4 Message Format
56
7.2.5 Headers
57
7.2.6 Data Formats 58
7.2.7 Delimiters 58
