Hioki 3560 - Page 45

33
────────────────────────────────────────────────────
5.1 Resistance Measurement Mode
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
OFF
The buzzer sounds at Hi
The buzzer sounds at Hi or Lo.
(5) Setting the buzzer mode
1. Use the (cursor right move) key to select the
last digit of the resistance lower limit setup
field.
2. Press the
(cursor right move) key again to
display the buzzer setup screen.
3. Use the + and keys to set the buzzer. Select
a mode from three available options: "OFF",
"IN", "HiLo."
(6) Setting end
Press the ENTER key to exit comparator setup. The
system returns to the measurement screen.
When the
is pressed, the screen changes to "(2)
Comparator number setup." The next comparators
can then be set continuously.
