Table 4.3.31 Image Types and Image Save Sizes
Image Type Image Save Size
Image only 640x480 pixels
Image + information 640x520 pixels
Image + information + comments 640x550 pixels
Saved images can be checked by using Explorer. Select [Saved Images] from the
[File] menu or click the [F9] key on your keyboard to display the folder where the
images are saved.
2. Entry Mode Selection Buttons
The following data entry modes are available:
Entry cancellation button:
Cancels the input of data.
Character entry button:
Allows the input of characters. Left-clicking any location on the screen where text is to
be inserted, the text insertion part is displayed black-on-white. Enter a text and click
the [ENTER] key to determine it. By clicking any other point on the window during
character input, the text insertion part moves to that point.
Straight line button:
Draws a straight line. Drag the mouse from the start point to the end point of the
straight line.
Arrow button:
Draws an arrow. Drag the mouse from the start point to the end point of an arrow.
Two-end arrow button:
Draws a two-end arrow. Drag the mouse from the start point to the end point of an
arrow.
Inner-size arrow button:
Draws an inner-size line without displaying a numerical value. Drag the mouse from
the start point to the end point of a line..
