Outer-size arrow button:
Draws an outer -size line without displaying a numerical value. Drag the mouse from
the start point to the end point of a line..
Inner-size display button:
Draws an inner-size line by displaying a numerical value. Drag the mouse from the
start point to the end point of a line..
Outer-size display button:
Draws an outer-size line by displaying a numerical value. Drag the mouse from the
start point to the end point of a line..
Circle button:
Draws a circle. Drag the mouse from the start point to the desired point to draw a
circle..
Square button:
Draws a square. Drag the mouse from the start point to the desired point to draw a
square..
Image adjustment button:
Calls an image adjustment screen. The brightness and contrast can be
adjusted on this screen. For the details, refer to 4.3.32 Image Balance
Window.
Delete selection button:
Selects the data to be deleted. The data can be selected in sequence by
pressing the [＜] or [＞] key (the selected data is highlighted in red.) [ALL]
selects all input data.
Clear button:
Deletes the input data selected using the above [Delete Select] button.
Save button:
Saves the image with data embedded. As a Save Image window appears,
enter the file name, and select the destination of save and the file type. If not
saving the image, click the [Cancel] button.
